4″ Bayonet Adapter TBA400
Original price was: $7.00.$6.20Current price is: $6.20.
TBA400; 1/8″ NPT X 4″ LONG; BAYONET ADAPTOR, 4″ LONG WITH 1/8″ NPT THREAD, SCREWDRIVER SLOT, SS CONSTRUCTIONÂ $6.20 EACH
Bayonet adapter is used to secure a sensor to a part. When used together, a bayonet fitting and bayonet adapter act as a spring-loading device for bottoming a thermocouple, RTD, or Thermistor hot junction in a hole. The fitting is designed for use on an 0.188 inch O.D. sensor. The TH-2760 fitting includes a lockcap, spring and spring stop, which requires brazing for assembly. We also supply this spring assembly with a compression fitting design to slide onto a probe.
The standard bayonet adapter requires a tapped 1/8 inch NPT or 3/8 24 hole for mounting. We also supply Metric Threaded Bayonet adapters. All standard components are nickel plated steel. PTSHEAT has Stainless Steel construction stock units ready to ship. TH-295-1, TH-295-2, TH-295-3, TH-295-4, TH-295-5, TH-298-1, TH-298-2. TCA-104-101, TCA-104-103, TCA-104-121, TCA-104-118, TCA-104-102, TCA-104-115, TCA-104-110, TCA-104-105, TCA-104-106, TCA-104, 107, TCA-104-107, TCA-104-108, TCA-104-111, TCA-104-127, TCA-104-116, TCA-104-126, TCA-104-128, TCA-104-131, TCA-132, H440-7-1, H440-7-1-NI
TBA400; 1/8″ NPT X 4″ LONG; BAYONET ADAPTOR, 4″ LONG WITH 1/8″ NPT THREAD, SCREWDRIVER SLOT, SS CONSTRUCTIONÂ $6.20 EACH
Product Description
We stock the Watlow Bayonet Fittings Part number TBA400 = 1/8-27 threads x 4″ OAL, Single PIN, Stainless Steel Construction for High Temperature and longer life!
TBA400;Â Â $6.20 EACH
Contact one of our Stocking office personnel for information on thermocouple mounting methods. Hundreds of units in stock. We stock standard and metric bayonet adapters. TH-295-1, TH-295-2, TCA-104-101, TCA-104-103, TCA-104-121, TCA-104-118, TCA-104-102, TCA-104-115, TCA-104-110, TCA-104-105, TCA-104-106, TCA-104, 107, TCA-104-107, TCA-104-108, TCA-104-111, TCA-104-127, TCA-104-116, TCA-104-126, TCA-104-128, TCA-104-131, TCA-132, H440-7-1, H440-7-1-NI.
With Single and Double pin arrangement. A Bayonet adapter is used to secure a sensor to a part. When used together, a bayonet fitting and bayonet adapter act as a spring-loading device for bottoming a thermocouple, RTD, or Thermistor hot junction in a hole. The standard fitting is designed for use on an 0.188 inch O.D. sensor. We also supply this spring assembly with a compression fitting design to slide onto a probe. The standard bayonet adapter requires a tapped 1/8 inch NPT or 3/8 24 threads for mounting. We also supply Standard and Metric Threaded adapters.
TBA400; 1/8″ NPT X 4″ LONG SINGLE PIN BAYONET ADAPTER WITH SCREWDRIVER SLOT:Â $6.20 EACH
Contact our sales engineers for help selecting and checking stock today!Â
Additional Information
Weight | 1 lbs |
---|---|
Dimensions | 1 × 0.5 × 0.5 in |
TH-295-2 | 1" LONG BAYONET FITTING 1/8" NPT X 1" LONG BAYONET FITTING |
TH-295-1 | BAYONET ADAPTOR, 7/8" LONG WITH 1/8" NPT THREAD, SCREWDRIVER SLOT, SS; TBA088 |
TH-295-4 | 1/8" NPT THREAD X 2" OAL BAYONET ADAPTER, SINGLE PIN, SCREWDRIVER SLOT, STAINLESS STEEL CONSTRUCTION |
TCA-104-115 | 1/8" NPT X 3-1/2" LONG BAYONET ADAPTER; SINGLE PIN, SCREWDRIVER SLOT |
Specifications Sheet
Click here for an informative spec sheet and selection guide:
Contact one of our sales engineers for help with selection or ordering!
